Shirita LED
Product info:
Linear light source on flexible PCB
Every 3 LEDs as a group can be separated
Parameters are calculated according to 1m
Reliability and long life
Protection class IP20
Product specification:
LED/m 60
LED Type SMD 3528
Color Cool White / Warm White
Current 400 mA
Voltage 12 VDC
Power 4.8 W
Luminous Flux 250 lm / 190 lm
Wavelenght/CCT 6000-6500 K / 3000-3500 K
Angle 120°
Product info:
Linear light source on flexible PCB
Every 3 LEDs as a group can be separated
Parameters are calculated according to 1m
Reliability and long life
Protection class IP54
Product specification:
LED/m 60
LED Type SMD 3528
Color Cool White / Warm White
Current 400 mA
Voltage 12 VDC
Power 4.8 W
Luminous Flux 185 lm / 200 lm
Wavelenght/CCT 6000-6500 K / 3000-3500 K
Angle 120°
Product info:
Linear light source on flexible PCB
Every 3 LEDs as a group can be separated
Parameters are calculated according to 1m
Reliability and long life
Protection class IP20
Product specification:
LED/m 30
LED Type SMD 5050
Color RGB / Cool White / Warm White
Current 600 mA
Voltage 12 VDC
Power 7,2 W
Luminous Flux 200 lm / 415 lm / 430 lm
Wavelenght/CCT R 610-625 nm G 515-525 nm B 460-470 nm / 6000-6500 K / 3000-3500 K
Angle 120°
Product info:
Linear light source on flexible PCB
Every 3 LEDs as a group can be separated
Parameters are calculated according to 1m
Reliability and long life
Protection class IP54
Product specification:
LED/m 30
LED Type SMD 5050
Color RGB / Cool White / Warm White
Current 600 mA
Voltage 12 VDC
Power 7,2 W
Luminous Flux 185 lm / 305 lm / 380 lm
Wavelenght/CCT R 610-625 nm G 515-525 nm B 460-470 nm / 6000-6500 K / 3000-3500 K
Angle 120°
Product info:
Linear light source on flexible PCB
Every 3 LEDs as a group can be separated
Parameters are calculated according to 1m
Reliability and long life
Protection class IP20
Product specification:
LED/m 60
LED Type SMD 5050
Color RGB / Cool White / Warm White
Current 1200 mA
Voltage 12 VDC
Power 14.4 W
Luminous Flux 420 lm / 845 lm / 810 lm
Wavelenght/CCT R 610-625 nm G 515-525 nm B 460-470 nm / 6000-6500 K / 3000-3500 K
Angle 120°
Product info:
Linear light source on flexible PCB
Every 3 LEDs as a group can be separated
Parameters are calculated according to 1m
Reliability and long life
Protection class IP54
Product specification:
LED/m 60
LED Type SMD 5050
Color RGB / Cool White / Warm White
Current 1200 mA
Voltage 12 VDC
Power 14.4 W
Luminous Flux 390 lm / 775 lm / 620 lm
Wavelenght/CCT R 610-625 nm G 515-525 nm B 460-470 nm / 6000-6500 K / 3000-3500 K
Angle 120°
Linear light source on flexible PCB. Every 3 LEDs as a group can be separated.Parameters are calculated according to 1m. Reliability and long life. Protection class IP54
LED/m
60
LED Type
SMD 5050
Color
RGB
Current
1200 mA
Voltage
12 VDC
Power
14.4 W
Luminous Flux
390 lm
Wavelenght/CCT
R 610-625 nm
Angle
120°
Product info:
Aluminium PCB High luminous efficiency
70%-80% Energy Saving
Certificates: CE,ROHS,EMC,LVD
Color uniformity
Parameters are calculated according to 1m
Product specification:
LED/m 72
LED Type SMD 5630
Color Cool White / Warm White
Current 1.8 A
Voltage 12 VDC
Power 21.6 W
Luminous Flux 2520 lm / 2435 lm
Wavelenght/CCT 6000-6500 K / 3000-3500 K
Angle 120°
